100m³ /H Capacity Bored Piling Mud Recycling System for Sale
Product Introduction
The Mud Recycling System, self-developed by TR Solids Control, mainly used to recycle the slurry essence piling constructions of circulation & counterflush drilling and shied in constructions of slurry balanced, can decrease the slurry discharge, cut tool-sticking accidents, and improve the drilling efficiency. Double screen mesh was adopted in filter system to improve working efficiency by 50% compared with the traditional single mesh one. Meanwhile, our desander has the properties of simple operation, easy maintenance as well as outstanding cleaning and purifying ability, long service life and high reliability.
This kind of mud recovery system is mainly used in mud solids wall taken modern foundation engineering construction, circulation drilling technology of large diameter pile and cut-off walls. The device makes the mud purification fully, for effective separation of slag. It reduces the sticking accidents, improves the drilling quality. During this process mud can be recycled fully, it reduces the cost and the pollution to environment.
Main Advantages of Our bored pilingd desanding plant:
- High mud handling capacity, sand can be removed efficiently.
- Mud reuse saves mud making materials and reduces construction cost.
- Effective separation of soil crusts, pore-forming efficiency is enhanced.
- Mud closed-circuit circulation mode and low ballast material moisture content are helpful to reduce environment pollution.
- It can improve quality and working efficiency of pore making in the pile foundation.
- The equipment for modular design and compact structure, making it easy to put in the construction and convenient to move.
Specifications of Our Bored Pile Desanding Plant
| Model | TRZX-50/25 | TRZX-100/50 | TRZX-200/50 |
| Fluid Capacity | ≤50m³/h | ≤100m³/h | ≤200m³/h |
| Sludge Treatment Capacity | ≤26T/h | ≤50m³/h | ≤50m³/h |
| Separation Point | 25μm | 50μm | 50μm |
| Shale Shaker | TRZS753 | TRZS753 | TRZS705 |
| Screen Area | Upper:700×1250 Bottom:750×900×2 | Upper:700×1250 Bottom:750×900×2 | Upper:750×900×2 Bottom:700×1250×3 |
| Vibration Motor | 1.0kw×2 | 1.0kw×2 | 1.5KW×2 |
| Matching Pump | TRSB4×3-12(15KW) | TRSB5×4-13(30KW) | TRSB6×5-13J(45KW) |
| Matching Hydrocyclone | DN100×4 | DN250×1 | DN250×2 |
| Tank Dimension | 2.1x1.5x2.6m | 3.05x2.0x1.2m | 3.6x2.1x1.2m |
| Dimension | | 3.12x2.2x2.38m | 3.7x2.2x2.54m |
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
